1. Product Overview
A Fully Automatic Horizontal Hydraulic Baler is designed for high-volume industrial recycling operations. Built with a heavy-duty steel structure and intelligent PLC control, this machine delivers continuous automatic feeding, compression, tying, and bale discharge. It significantly reduces labor costs while producing uniform, high-density bales for efficient storage and transportation in recycling centers, paper mills, and waste management facilities.
📹 Recommended YouTube Running Videos
-
REDSTAR Horizontal Baler Running
▶️ https://youtube.com/shorts/Y_SBzE9DfZg?si=7yg7Y9WCpbJ__EKg
Shows REDSTAR hydraulic horizontal baler, including RSD-60T / RSD-80T / RSD-100T in action. -
Horizontal Baler Loading & Operation
▶️ https://youtube.com/shorts/PhlGTwbrWlw?si=QwLnsGporqjIh64K
Demonstrates H80 automatic horizontal baler being loaded and tied with one-touch operation. -
Fully Automatic Horizontal Baler for Cardboard & PET
▶️ https://youtube.com/shorts/3vHrc7wbY3Q?si=CRkrjtFk4yYXrOZb
Generic fully auto baler crushing cardboard and PET — great as a demo video even if exact tonnage isn’t shown. -
Automatic Horizontal Baler (General Demo)
▶️https://youtube.com/shorts/iKbUzvedpBE?si=M_KqYCGMkdIJ3IRe
Enerpat automatic horizontal baler compressing mixed waste — useful to show op
2.What Is A Fully Automatic Horizontal Hydraulic Baler
A fully automatic horizontal hydraulic baler is an industrial recycling machine designed to compress loose recyclable materials into dense, standardized bales using horizontal compression and hydraulic power. Unlike vertical or semi-automatic balers, this machine operates in a continuous cycle, significantly improving throughput while reducing manpower requirements.
It is widely used in recycling centers, paper mills, waste transfer stations, logistics hubs, and manufacturing plants where large volumes of recyclable waste are generated daily.
2. Key Features And Functional Advantages
Heavy-Duty Structure And Industrial-Grade Design
Reinforced All-Steel Machine Frame
The entire machine frame is manufactured from thickened carbon steel plates with precision welding. This rigid structure ensures long-term durability and prevents deformation during continuous high-pressure operation.
Wear-Resistant Compression Chamber
Key wear areas inside the compression chamber are reinforced to withstand abrasive materials such as cardboard, PET bottles, and aluminum cans, extending service life and reducing maintenance frequency.
Fully Automatic Operation System
One of the most important advantages of this baler is its true fully automatic working process:
-
Automatic material feeding via conveyor or air system
-
Automatic hydraulic compression cycle
-
Automatic wire tying with stable knot performance
-
Automatic bale length control through PLC
-
Automatic bale pushing and continuous discharge
This uninterrupted workflow enables 24/7 industrial operation with minimal operator intervention.
High-Efficiency Hydraulic Power System
-
Large-diameter hydraulic cylinders provide strong and stable compression force
-
High-quality plunger oil pumps ensure consistent pressure output
-
Optimized hydraulic circuit design reduces energy consumption
The result is high bale density with lower power cost per ton processed.
Intelligent PLC Control System
The baler is equipped with an industrial-grade PLC control system featuring:
-
Touchscreen human–machine interface
-
Adjustable bale length and compression pressure
-
Real-time operation monitoring
-
Automatic fault diagnosis and alarm display
-
Emergency stop and safety interlock protection
This system guarantees reliable performance and easy operation, even for less-experienced operators.
High-Density And Uniform Bale Output
-
Produces compact, uniform bales
-
Improves warehouse stacking efficiency
-
Maximizes container loading capacity
-
Reduces transportation and logistics costs
Uniform bale size is especially important for downstream recycling buyers and export logistics.
3. Product Applications
Applicable Materials
-
Waste paper (OCC, cardboard, newspaper, mixed paper)
-
Plastic bottles (PET), plastic film, PP and PE materials
-
Aluminum cans and light metal scrap
-
Textile waste, fiber, and packaging materials
Typical Application Scenarios
-
Recycling centers and sorting plants
-
Paper mills and packaging factories
-
Municipal solid waste stations
-
Logistics and distribution hubs
-
Manufacturing plants with recyclable by-products
This machine is designed to meet the demands of large-scale B2B recycling operations.
4. Technical Specifications
| Model | Hydraulic Power (Ton) | Bale Size (W×H×L) mm | Feed Opening Size (L×W) mm | Bale Density (kg/m³) | Bale Tying Lines | Output (Ton/Hr) | Motor Power (kW/HP) | Machine Size (L×W×H) mm | Machine Weight (Ton) |
| 30QT | 30 | 500×500×(300–1000) | 950×450 | 250–300 | 3 | 1–1.5 | 11 / 15 | 5000×2750×1800 | 4 |
| 40QT | 40 | 720×720×(300–1500) | 1150×680 | 350–450 | 4 | 1.5–2.5 | 15 / 20 | 6100×3200×1950 | 6.5 |
| 40QT-P | 40 | 720×800×(300–1500) | 1350×680 | 350–450 | 4 | 2–3 | 15 / 20 | 6600×3200×2100 | 7 |
| 60QT | 60 | 750×850×(300–1600) | 1500×700 | 400–500 | 4 | 3–4 | 22 / 30 | 6900×3300×2100 | 8 |
| 60QT-P | 60 | 1100×800×(300–1600) | 1600×1050 | 400–500 | 4 | 3–6 | 30 / 40 | 7100×4200×2100 | 9.5 |
| 80QT | 80 | 1100×800×(300–1800) | 1650×1050 | 450–550 | 4 | 4–7 | 37 / 50 | 7900×4200×2100 | 11 |
| 80QT-P | 80 | 1100×900×(300–1800) | 1800×1050 | 450–550 | 4 | 5–8 | 37 / 50 | 8200×4200×2200 | 12 |
| 100QT | 100 | 1100×900×(300–2000) | 1800×1050 | 500–600 | 4 | 6–10 | 45 / 60 | 8400×4300×2400 | 13.5 |
| 100QT-P | 100 | 1100×1100×(300–2000) | 2000×1050 | 500–600 | 4 | 7–11 | 45 / 60 | 8800×4300×2400 | 15 |
| 120QT | 120 | 1100×1100×(300–2100) | 2000×1050 | 550–650 | 5 | 8–13 | 52 / 70 | 9100×4300×2400 | 17 |
| 120QT-P | 120 | 1100×1250×(300–2100) | 2200×1050 | 550–650 | 5 | 9–14 | 60 / 80 | 9500×4300×2600 | 18 |
| 150QT | 150 | 1100×1100×(300–2100) | 2200×1050 | 600–750 | 5 | 10–16 | 85 / 114 | 9800×4300×2400 | 20 |
| 150QT-P | 150 | 1100×1250×(300–2100) | 2400×1050 | 600–750 | 5 | 12–18 | 93 / 124 | 10200×4300×2600 | 22 |
| 200QT | 200 | 1100×1100×(300–2100) | 2400×1050 | 700–850 | 5 | 14–20 | 101 / 135 | 10500×4370×2500 | 30 |
| 200QT-P | 200 | 1100×1250×(300–2100) | 2600×1050 | 700–850 | 5 | 15–22 | 110 / 147 | 11000×4370×2700 | 32 |
| 250QT | 250 | 1100×1250×(300–2100) | 2800×1050 | 850–1000 | 5 | 16–25 | 110 / 147 | 12000×4468×2700 | 35 |
5 . How To Choose The Right Model – Practical Selection Guide
Choosing the correct fully automatic horizontal baler is critical for maximizing efficiency and return on investment.
Consider Your Material Type
-
Paper and cardboard require higher compression force for dense bales
-
Plastic film needs larger feeding openings
-
Bottles and cans benefit from reinforced chambers
Evaluate Required Processing Capacity
Estimate your daily or hourly throughput. Higher capacity operations should select models with larger motors and stronger hydraulic systems.
Confirm Bale Size Requirements
Different recycling buyers and transport systems may require specific bale dimensions. Always match the baler to downstream needs.
Check Factory Space And Power Supply
Ensure your site can accommodate the machine dimensions and local voltage standards.
Select The Appropriate Automation Level
Fully automatic models are ideal for high-volume operations with limited labor availability.
Safety Design And Operator Protection
-
Emergency stop buttons
-
Hydraulic overload protection
-
Safety interlock systems
-
Automatic fault shutdown
All safety features are designed to meet industrial operation standards and protect both operators and equipment.
Maintenance And Long-Term Reliability
Thanks to its modular design and high-quality components:
-
Daily maintenance is simple and fast
-
Spare parts are easy to replace
-
Downtime is minimized
This ensures low lifetime operating costs and long-term stable performance.
6.Why Choose Our Fully Automatic Horizontal Baler
-
Proven performance in global recycling markets
-
Heavy-duty construction for industrial use
-
Stable automation and intelligent control
-
Factory-direct supply with competitive pricing
-
Professional technical support and after-sales service
Our balers are designed not only to work today, but to perform reliably for years.
Ideal For B2B Buyers And Industrial Projects
This fully automatic horizontal baler is widely used by:
-
Recycling plant investors
-
Waste management companies
-
Equipment distributors and dealers
-
Government and municipal projects
-
Large manufacturing groups
It is a smart investment for scalable, professional recycling operations.
7 .Conclusion
A Fully Automatic Horizontal Hydraulic Baler is the ideal solution for businesses seeking high efficiency, reduced labor costs, and consistent bale quality. With intelligent automation, durable steel construction, and flexible customization options, this machine delivers long-term value for industrial recycling applications worldwide.
